焊接變位機是作為一種通用、的工業自動焊接設備越來越多的被應用到各種行業，操作者須具備基本的焊接變位機小常識，所以今天山東數控焊接設備廠家為大家分享下焊接變位機在使用過程中可能出現的機械故障以及參考解決方案。

As a general and efficient industrial automatic welding equipment, welding positioner is more and more applied to various industries. Operators must have basic knowledge of welding positioner. Therefore, Shandong CNC welding equipment manufacturer will share with you the possible mechanical faults and reference solutions of welding positioner during its use.

1.工作臺不回轉；

1. The workbench does not rotate;

（1）觸點接觸不好，線圈故障；處理方法：處理接觸器觸點，必要時更換接觸器。

(1) Poor contact and coil fault; Handling method: handle the contactor contact and replace the contactor if necessary.

（2）熱繼電器失靈；處理方法：更換熱繼電器或使其復位。

(2) Thermal relay failure; Treatment method: replace the thermal relay or reset it.

（3）按鈕發生故障；處理方法：修理或更換按鈕。

(3) Button failure; Handling method: repair or replace the button.

（4）電機抱閘路線斷開；處理方法；檢查電機抱閘裝置，將負載接線端子緊固，使其接觸良好

(4) The motor band brake line is disconnected; Treatment method; Check the motor band brake device and fasten the load terminal to ensure good contact

（5）變頻器工作不正常；處理方法：重新設置變頻器

(5) The frequency converter does not work normally; Processing method: reset the frequency converter

2.按下按鈕后，升降動作沒有動作；

2. After pressing the button, the lifting action does not act;

（1）限位機械觸點故障；處理方法：更換限位。

(1) Limit mechanical contact failure; Treatment method: replace the limit.

（2）按鈕觸點接觸不良或按鈕復位彈簧損壞處理方法：如修復不了，必要時更換按扭

(2) Treatment method for poor contact of button contact or damage of button return spring: if it cannot be repaired, replace the button if necessary

（3）熱繼電器故障；處理方法：調整整定電流或更換熱繼電器

(3) Thermal relay fault; Treatment method: adjust the setting current or replace the thermal relay

（4）負載接線端子接觸不良；處理方法：檢查接觸器并處理必要時更換接觸器，緊固負載接線端子

(4) Poor contact of load terminal; Handling method: check the contactor and handle it. If necessary, replace the contactor and fasten the load terminal

3.變位機回轉工作臺回轉速度不可調節；

3. The rotation speed of the rotary table of the positioner cannot be adjusted;

（1）遠控開關手控的調速電位器失靈；處理方法：更換調速電位器

(1) The manual speed regulating potentiometer of the remote control switch fails; Treatment method: replace the speed regulating potentiometer

（2）正向，反向繼電器不動作；處理方法：檢查接線是否松動，繼電器有無故障，將線擰牢或更換繼電器。

(2) Forward and reverse relays do not act; Treatment method: check whether the wiring is loose and whether the relay is faulty. Screw the wire firmly or replace the relay.

(3)變頻器面板接觸松動；處理方法：檢查變頻器，緊固螺絲使其接觸良好。

(3) Loose contact of frequency converter panel; Treatment method: check the frequency converter and tighten the screws to ensure good contact.

對焊接變位機這一焊接設備，可以說上述問題，是非常重要的，同時，也涉及到了基礎知識及內容，所以，大家應認真對待和進行，不能有半點馬虎和松懈，以免影響到知識的掌握和運用，從而，讓自己得不償失了。關注我們http://m.myp3.cn更多了解！

It can be said that the above problems are very important for welding positioner, which involves basic knowledge and content. Therefore, we should treat and carry out them seriously, and should not be careless or lax, so as not to affect the mastery and application of knowledge, thus making our gains outweigh our losses. Follow us http://m.myp3.cn Learn more!
